Sonly F9 Series

U388TSF9U388TSF9

Servo model, optimized with high-torque motor and chrome screw/barrel for PET preforms. Includes Double Core Pullers, Air Ejectors, and Conveyor. (CE Certified)U150TSF9 F9系列注塑機以極為嚴謹的理念設計，以「一機多用，綜合使用」為主要宗旨，外觀新穎，結構緊湊，性能優良。

Worldwide ShippingDelivery to any country

Shipping QuotationRequest a complete invoice

24/7 Technical SupportBefore and after sales

Factory WarrantyDirect manufacturer support

Chat on WhatsApp Request Quotation

A sales engineer will respond as soon as possible.销售工程师将尽快回复您。

Search Tags

U388TSF9

Servo model, optimized with high-torque motor and chrome screw/barrel for PET preforms. Includes Double Core Pullers, Air Ejectors, and Conveyor. (CE Certified)

SPECIFICATIONS - U388TSF9
INTERNATIONALLY RECOGNIZED MODEL	2840
INJECTION	Unit	A	B	C	D
Screw Diameter	mm	65	70	75	80
Screw L/D Ratio	L/D	23.7	23.6	22	20.6
Theoretical Shot Volume	cm³	1247.1	1446.3	1660.3	1889
Injection Pressure	Mpa	198.8	171.4	149.3	131.3
Theoretical Shot Weight	g	1134.8	1316.1	1510.9	1719
Theoretical Injection Rate	mm/s	150.0
Theoretical Shot Weight	oz	39.8	46.2	53.0	60.3
Screw Speed	rpm	246
CLAMPING DEVICE
Clamping Force	Kn	3880
Toggle Stroke	mm	710
Space Between Tie Bars	mm	760×685
Max. Mould Height	mm	675
Min. Mould Height	mm	280
Ejector Stroke	mm	170
Ejector Force	Kn	99
Ejector Number		12+1
Die Hole Diameter	mm	160
OTHER
System Pressure	Mp	17.5
Heater Power	Kw	27
Oil Tank Capacity	L	700
Machine Weight	Ton	13.5
Boundary Dimension (L×W×H)	m	7.2×2×2.46
Servo Driver Capacity	Kw	65
