Sonly F9 Series

F9-285TS 620565 SERVO MOTOR MACHINEF9-285TS 620565 SERVO MOTOR MACHINE

U150TSF9 The F9 series of injection molding machine is designed from extremely austere concept, with the main purpose of "One machine with multi function, comprehensive usage", it has a novel appearance, compact structure and excellent performance.U150TSF9 F9系列注塑機以極為嚴謹的理念設計，以「一機多用，綜合使用」為主要宗旨，外觀新穎，結構緊湊，性能優良。

Worldwide ShippingDelivery to any country

Shipping QuotationRequest a complete invoice

24/7 Technical SupportBefore and after sales

Factory WarrantyDirect manufacturer support

Chat on WhatsApp Request Quotation

A sales engineer will respond as soon as possible.销售工程师将尽快回复您。

Search Tags

SPECIFICATIONS - U285TSF9
INTERNATIONALLY RECOGNIZED MODEL		1280
INJECTION	Unit	A	B	C
INJECTION
SCREW DIAMETER	mm	55	60	65
SCREW L/D RATIO	L/D	24	22	20.3
THEORETICAL SHOT VOLUME	cm³	655.4	780.0	915.4
INJECTION PRESSURE	Mpa	194.3	163.3	139.2
THEORETICAL SHOT WEIGHT	g	596.4	709.8	833.0
THEORETICAL INJECTION RATE	mm/s	140.0
THEORETICAL SHOT WEIGHT	oz	20.9	24.9	29.2
SCREW SPEED	rpm	250
CLAMPING DEVICE
CLAMPING FORCE	Kn	2850
TOGGLE STROKE	mm	590
SPACE BETWEEN TIE BARS	mm	620×565
MAX.MOULD HEIGHT	mm	600
MIN.MOULD HEIGHT	mm	200
EJECTOR STROKE	mm	150
EJECTOR FORCE	Kn	77
EJECTOR NUMBER		12+1
DIE HOLE DIAMETER	mm	160
OTHER
SYSTEM PRESSURE	Mp	17.5
HEATER POWER	Kw	21.5
OILTANK CAPACITY	L	300
MACHINE WEIGHT	Ton	9.4
BOUNDARY DIMENSION (L×W×H)	m	6.7×1.6×2.4
