U238TS 530x530MM SERVO MOTOR MACHINE 注塑機U238TS
1.Complete models Sonly has invested amount of money in the continuous design and development of 28 models of U-TS series of 98-3400 tons, and the one-time development of casting wood molds to form a series of modules … 索力投入大量資金持續設計開發U-TS系列98-3400噸28個型號，一次性開發鑄造木模，形成系列模組，滿足各種個性化需求和成本- 有效的。 2.重複精度高 具備20多年研發塑機的實務經驗，採用伺服系統，穩定快速、高效節能、噪音低、重複精度高。
Get a Quote 索取报价|
SPECIFICATIONS |
U238TS |
规格 |
||||
|
INTERNATIONALLY RECOGNIZED MODEL |
1094 |
1094 |
||||
|
INJECTION UNIT |
A |
B |
C |
注射单元 |
||
|
SCREW DIAMETER |
mm |
55 |
60 |
65 |
螺杆直径 |
|
|
SCREW L/D RATIO |
L/D |
24 |
22 |
20.3 |
螺杆L/D比率 |
|
|
SHOT VOLUME |
cm3 |
593.2 |
706 |
828.6 |
射出量 |
|
|
INJECTION PRESSURE |
Mpa |
184.5 |
155 |
132.1 |
注射压力 |
|
|
SCREW SPEED |
rpm |
160 |
螺杆速度 |
|||
|
SHOT WEIGHT |
g |
540 |
642 |
754 |
射出重量（克） |
|
|
SHOT WEIGHT |
oz |
19.048 |
22.646 |
26.597 |
射出重量（盎司） |
|
|
CLAMPING UNIT |
夹紧单元 |
|||||
|
CLAMPING FORCE |
Kn |
2380 |
夹紧力 |
|||
|
TOGGLE STROKE |
mm |
520 |
开合行程 |
|||
|
SPACE BETWEEN TIE BARS |
mm |
530*530 |
支撑杆间距 |
|||
|
MOLD HEIGHT |
mm |
460-670 |
模具高度 |
|||
|
MOLD PLATE THICKNESS |
mm |
40 |
模具板厚度 |
|||
|
GENERAL CHARACTERISTICS |
一般特征 |
|||||
|
MACHINE DIMENSION (L×W×H) |
mm |
4600×1850×2750 |
机器尺寸（长×宽×高） |
|||
|
MACHINE WEIGHT |
kg |
6300 |
机器重量 |
|||
|
ELECTRICITY |
KW |
70 |
电力 |
|||
|
AIR PRESSURE |
Mpa |
0.6 |
气压 |
|||
|
OIL TEMPERATURE |
℃ |
55 |
油温 |
|||
|
NOISE LEVEL |
db |
78 |
噪音水平 |
|||
|
