U218TS 510x510MM SERVO MOTOR MACHINE 注塑機U218TS
1.Complete models Sonly has invested amount of money in the continuous design and development of 28 models of U-TS series of 98-3400 tons, and the one-time development of casting wood molds to form a series of modules … 索力投入大量資金持續設計開發U-TS系列98-3400噸28個型號，一次性開發鑄造木模，形成系列模組，滿足各種個性化需求和成本- 有效的。 2.重複精度高 具備20多年研發塑機的實務經驗，採用伺服系統，穩定快速、高效節能、噪音低、重複精度高。
Get a Quote 索取报价|
SPECIFICATIONS 规格 |
U218TS |
|||
|
INTERNATIONALLY RECOGNIZED MODEL 国际认可型号 |
1067 |
|||
|
INJECTION UNIT 注射单元 |
A |
B |
C |
|
|
INJECTION UNIT 注射单元 |
||||
|
SCREW DIAMETER 螺杆直径 |
mm |
45 |
50 |
55 |
|
SCREW L/D RATIO 螺杆长径比 |
L/D |
24.4 |
22 |
20 |
|
SHOT VOLUME 注射量 |
cm3 |
460 |
569 |
688 |
|
INJECTION PRESSURE 注射压力 |
Mpa |
227.5 |
184.3 |
152.3 |
|
SCREW SPEED 螺杆转速 |
rpm |
180 |
||
|
SHOT WEIGHT 注射重量 |
g |
419 |
518 |
627 |
|
SHOT WEIGHT 注射重量 |
oz |
14.78 |
18.27 |
22.11 |
|
CLAMPING UNIT 模具夹紧单元 |
||||
|
CLAMPING FORCE 夹紧力 |
Kn |
2180 |
||
|
TOGGLE STROKE 开模行程 |
mm |
500 |
||
|
SPACE BETWEEN TIE BARS 横梁间距 |
mm |
510*510 |
||
|
MAX.MOULD HEIGHT 最大模具高度 |
mm |
530 |
||
|
MIN.MOULD HEIGHT 最小模具高度 |
mm |
200 |
||
|
EJECTOR STROKE 注射器行程 |
mm |
150 |
||
|
EJECTOR FORCE 注射器力 |
Kn |
70 |
||
|
EJECTOR NUMBER 注射器数量 |
8+1 |
|||
|
OTHERS 其他 |
||||
|
DIE HOLE DIAMETER 模孔直径 |
mm |
Φ60 |
||
|
MACHINE DIMENSION 机器尺寸 |
mm |
3800x1000x2700 |
||
|
MACHINE WEIGHT 机器重量 |
kg |
8500 |
||
|
